• Chrome front bumper w/black rub strip
• Painted rear step bumper w/step pad
• Black body-side molding w/bright trim
• Wheel opening flares
• Argent painted grille
• Single rectangular halogen headlamps
• Daytime running lamps
• Cargo area lamp
• Dual black foldaway mirrors
• Solar-Ray tinted glass (all windows)
• Intermittent windshield wiper system
• Removable tailgate
• Insulation under dash & floor covering

• 3-passenger vinyl trim, bench seat w/outboard head restraint, folding backrest
• 3-passenger folding rear bench seat w/matching trim
• Color-keyed molded vinyl floor covering
• Simulated leather steering wheel
• Passlock theft deterrent security system
• Lights-on warning buzzer
• Heater/defogger w/side window defoggers, rear passenger heating ducts
• ETR AM/FM stereo-inc: seek-scan, digital clock, 4 speakers
• Glove box w/latched door
• Passenger side instrument panel storage bin
• Dual cup holders on instrument panel
• Dual dash mounted power outlets
• Cigarette lighter
• Molded plastic door trim panels w/dual padded armrests
• Color-keyed cloth headliner
• Dual color-keyed padded cloth sunshades w/RH vanity mirror
• Passenger assist handles
• Lighting-inc: dome, reading, ashtray, glove-box, illuminated entry feature, underhood
• Dual rear coat hooks

• Four-wheel anti-lock brake system
• Manual lap/shoulder safety belts, front/rear outboard seat positions
• Front outboard shoulder belt height adjusters
• Manual lap safety belts, center seat positions
• Head restraints, front seat
• Daytime running lamps
• Side door guard beams
• Single note horn

DELUXE FRONT APPEARANCE PKG

• color-keyed grille w/bright trim
• dual composite halogen headlamps
• dual horns

6.5L (395) HD V8 TURBO DIESEL ENGINE

• dual 600 CCA batteries
• HD radiator
• engine oil cooler
• extra sound insulation
• block heater
• glow plugs
• two-stage fuel filter w/integral fuel heater/water separator w/instrument panel warning light
• front black bumper guards

HD 4-SPEED ELECTRONICALLY-CONTROLLED AUTOMATIC TRANSMISSION W/OD

• HD aux trans oil cooler
• brake/trans shift interlock

DUAL REAR WHEELS

• roof marker/tailgate lamps *deletes std Body-Side Molding* *deletes rear wheel opening flares*

HD TRAILERING SPECIAL EQUIPMENT

• weight-distributing hitch platform
• HD hazard flasher

10,000# GVWR

• (4500 front/7500 rear)
• springs (4500 front/7500 rear)
• axles (4500 front/ 7500 rear)

WIDESIDE BODY

• (STD)

LT225/75R16D ON-OFF ROAD SBR BSW FRONT TIRES

• **D & H tax inc**

(4) LT225/75R16D ON-OFF ROAD SBR BSW REAR TIRES

• **D & H tax inc**

LT225/75R16D ON-OFF ROAD SBR BSW SPARE TIRE

• **D & H tax inc**

CONVENIENCE GROUP

• tilt wheel
• cruise control

SLE MARKETING OPTION PKG 3

• SLE decor
• air cond
• tilt wheel
• cruise control
• ETR AM/FM stereo w/cassette

FRONT HIGH-BACK RECLINING BUCKET SEATS

• inboard armrests
• roof/floor console
• dual adj headrests
• driver pwr lumbar
• storage pockets behind seat
• 3-passenger adjustable split-back rear bench seat w/center fold-down armrest/ headrests

ETR AM/FM STEREO W/REMOTE COMPACT DISC,STEREO CASSETTE, AUTO TONE CONTROL

• seek-scan
• digital clock
• theft lock
• speed compensated volume
• enhanced performance speaker system

SOLID PAINT

• (STD)

• 10,000 lbs GVWR
• 4.10 Rear Axle Ratio
• Air Conditioning
• Chromed Rear Bumper with Step Pad
• Deep Tinted Glass
• Federal Emissions
• Four Trim Rings and Hub Caps
• Front License Plate Bracket
• Front LT225/75R16D SBR On-Off Road Tires
• Heavy Duty Front Springs
• High Capacity Air Cleaner
• Locking Rear Differential
• Onyx Black
• Power Door Locks
• Rear LT225/75R16D SBR On-Off Road Tires
• Spare LT225/75R16D SBR On-Off Road Tire
• Tilt Wheel and Speed Control
• Wideside Body Code
• 4-Speed Automatic Transmission with Overdrive
• 6.5L V8 Turbo Diesel Engine
• Deluxe Front Appearance Package
• Dual Rear Wheels
• Heavy Duty Trailering Equipment
• 12V power outlets 3 12V power outlets
• 4WD type Part-time 4WD
• ABS Brakes 4-wheel antilock (ABS) brakes
• ABS Brakes Three channel ABS brakes
• Air conditioning Yes
• Alternator Type Alternator
• Antenna Fixed audio antenna
• Ashtray
• Basic warranty 36 month/36,000 miles
• Battery charge warning
• Battery type Dual lead acid batteries
• Beverage holders Front beverage holders
• Block heater Engine block heater
• Body panels Fully galvanized steel body panels with side impact beams
• Bodyside insert Chrome bodyside insert
• Bodyside moldings Black bodyside moldings
• Box style Standard style pickup box
• Brake type Front disc and rear drum brakes
• Bumper insert Chrome front bumper insert
• Bumper rub strip front Black front bumper rub strip
• Bumper rub strip rear Black rear bumper rub strip
• Bumpers front Chrome front bumper
• Bumpers rear Chrome rear bumper
• Cab mounted cargo light
• Cabback insulator
• Child door locks Manual rear child safety door locks
• Cigarette lighter Front cigarette lighter
• Clearance lights Cab clearance lights
• Climate control Manual climate control
• Clock Digital clock
• Compressor Turbo
• Corrosion perforation warranty 72 month/100,000 miles
• Cruise control
• Cylinder head material Iron cylinder head
• Day/Night rearview mirror
• Deluxe sound insulation
• Door ajar warning
• Door bins front Driver and passenger door bins
• Door bins rear Rear door bins
• Door handle material Black door handles
• Door locks Power door locks
• Door mirror style Black door mirrors
• Door mirror type Standard style side mirrors
• Drive type Four-wheel drive
• Driver seat direction Driver seat with 2-way directional controls
• Emissions Federal emissions
• Engine 6.5L V-8 turbo, diesel, engine with 195HP
• Engine block material Iron engine block
• Engine compartment light
• Engine Configuration V8
• Engine cooler Engine oil cooler
• Engine Location Front mounted engine
• Engine Mounting direction Longitudinal mounted engine
• Engine Short 6.5L V-8
• Engine/electric motor temperature gauge
• Fenders Black fender flares
• First-row windows Manual first-row windows
• Floor coverage Full floor coverage
• Floor covering Full vinyl floor covering
• Folding door mirrors Manual folding door mirrors
• Folding rear seats Full folding rear seats
• Front anti-roll Heavy-duty front anti-roll bar
• Front head restraint control Manual front seat head restraint control
• Front head restraints Height adjustable front seat head restraints
• Front reading lights
• Front seat type Bench front seat
• Front seat upholstery Vinyl front seat upholstery
• Front seatback upholstery Vinyl front seatback upholstery
• Fuel Type Diesel
• Gearshifter material Urethane gear shifter material
• Glove box Illuminated glove box
• Grille style Chrome grille
• HD front springs Heavy-duty front springs
• Headlight type Reflector headlights
• Headlights Halogen headlights
• Headlights on reminder
• Headliner coverage Full headliner coverage
• Headliner material Cloth headliner material
• Height adjustable seatbelts Front height adjustable seatbelts
• High mount stop light High mounted center stop light
• Ignition Compression ignition system
• Ignition type Mechanical
• Illuminated glove box
• Immobilizer Passlock II immobilizer
• Instrumentation display Analog instrumentation display
• Key in vehicle warning
• License plate front bracket Front license plate bracket
• Limited slip differential Mechanical limited slip differential
• Lock-up transmission
• Locking hub control Auto locking hub control
• Manual driver seat controls Driver seat manual fore/aft control
• Manual passenger seat controls Passenger seat manual fore/aft control
• Multiple headlights Multiple enclosed headlights
• Number of doors 4 doors
• Oil pressure gauge
• Overdrive transmission
• Paint Non-metallic paint
• Passenger doors rear left Conventional left rear passenger door
• Passenger doors rear right Conventional right rear passenger door
• Passenger seat direction Front passenger seat with 2-way directional controls
• Powertrain type ICE
• Powertrain warranty 36 month/36,000 miles
• Radiator Heavy-duty radiator
• Radio AM/FM
• Rear bumper step
• Rear cargo door Tailgate
• Rear head restraint control 2 rear seat head restraints
• Rear head restraint control Manual rear seat head restraint control
• Rear head restraints Height adjustable rear seat head restraints
• Rear seat direction Front facing rear seat
• Rear seat folding position Fold forward rear seatback
• Rear seat upholstery Vinyl rear seat upholstery
• Rear seatback upholstery Vinyl rear seatback upholstery
• Rear seats fixed or removable Fixed rear seats
• Rear seats Rear bench seat
• Rear Springs Regular grade rear springs
• Rear under seat ducts Rear under seat climate control ducts
• Rear window trim Black rear window trim
• Rear windshield Fixed rear windshield
• Reclining rear seats Manual reclining rear seats
• Roadside warranty 36 month/36,000 miles
• Running lights Daytime running lights
• Seating capacity 6
• Second-row windows Manual second-row windows
• Seek scan
• Shock absorbers Gas-pressurized shock absorbers
• Spare tire Full-size spare tire with steel wheel
• Spare tire location Crank-down spare tire
• Speakers number 4 speakers
• Speakers Standard grade speakers
• Special paint Monotone paint
• Speed sensitive steering Speed sensitive power steering
• Sport steering wheel
• Springs front Front torsion springs
• Springs rear Rear leaf springs
• Steering Hydraulic power-assist steering system
• Steering type Re-circulating ball steering
• Steering wheel material Urethane steering wheel
• Steering wheel tilt Manual tilting steering wheel
• Sun visor strip
• Suspension ride type front Independent front suspension
• Suspension ride type rear Rigid axle rear suspension
• Suspension Standard ride suspension
• Suspension type front Short and long arm front suspension
• Suspension type rear Leaf spring rear suspension
• Tachometer
• Tailpipe Stainless steel single exhaust
• Tinted windows Deep tinted windows
• Tires LT245/75SR16 AS BSW front and rear tires
• Tow hooks front 2 front tow hooks
• Towing hitch Trailer hitch
• Towing wiring harness Trailer wiring harness
• Transfer case Manual transfer case shift
• Transmission 4-speed automatic
• Transmission electronic control
• Transmission oil cooler Heavy-duty transmission oil cooler
• Transmission Type Automatic
• Trim rings Wheel trim rings
• Trip odometer
• Variable panel light Variable instrument panel light
• Ventilated brakes Front ventilated disc brakes
• Visor passenger mirror Passenger visor mirror
• Voltmeter
• Wheel covers Wheel hub covers
• Wheels 16 x 6-inch front and dual rear painted styled steel wheels
• Window Trim Black side window trim
• Windshield trim Black windshield trim
• Wipers Variable intermittent front windshield wipers

• Electrical
• Cold Cranking Amps @ 0° F (Primary): 600
• Cold Cranking Amps @ 0° F (2nd): 600
• Maximum Alternator Capacity (amps): 100
• Maximum Alternator Watts: 1200
• Cooling System
• Total Cooling System Capacity (qts): 23.8
• Total Cooling System Capacity (qts): 17.1
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 4500
• Gross Axle Wt Rating - Rear (lbs): 7500
• Gross Axle Wt Rating - Rear (lbs): 6084
• Curb Weight - Front (lbs): 3349
• Curb Weight - Rear (lbs): 2526
• Gross Vehicle Weight Rating Cap (lbs): 10,000
• Gross Vehicle Weight Rating Cap (lbs): 9200
• Gross Combined Wt Rating (lbs): 14,500
• Gross Combined Wt Rating (lbs): 13,500
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
• Dead Weight Hitch - Max Tongue Wt. (lbs): 500
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 10,000
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 1000
• Suspension
• Suspension Type - Front: Torsion Bar
• Suspension Type - Rear: 2-Stage Multi-Leaf
• Spring Capacity - Front (lbs): 4500
• Spring Capacity - Rear (lbs): 7500
• Spring Capacity - Rear (lbs): 6084
• Axle Type - Front: Independent GM
• Axle Type - Rear: Full-Floating
• Axle Capacity - Front (lbs): 4500
• Axle Capacity - Rear (lbs): 7500
• Axle Capacity - Rear (lbs): 6084
• Axle Ratio (:1) - Front: 4.10
• Axle Ratio (:1) - Rear: 4.10
• Shock Absorber Diameter - Front (mm): 35
• Shock Absorber Diameter - Rear (mm): 35
• Stabilizer Bar Diameter - Front (in): 1.18
• Brakes
• Brake Type: Power
• Brake ABS System: Four Wheel
• Disc - Front (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 12.50 x 1.50
• Front Brake Rotor Diam x Thickness (in): 12.50 x 1.26
• Drum - Rear (Yes or ): Yes
• Rear Drum Diam x Width (in): 13.0 x 3.5
• Tires
• Front Tire Order Code: XHR
• Front Tire Order Code: XHH
• Rear Tire Order Code: YHR
• Rear Tire Order Code: YHH
• Spare Tire Order Code: ZHR
• Spare Tire Order Code: ZHH
• Front Tire Size: LT225/75R16D
• Front Tire Size: LT245/75R16E
• Rear Tire Size: LT225/75R16D
• Rear Tire Size: LT245/75R16E
• Spare Tire Size: LT225/75R16D
• Spare Tire Size: LT245/75R16E
• Front Tire Capacity (lbs): 2335
• Rear Tire Capacity (lbs): 1875
• Rear Tire Capacity (lbs): 3042
• Spare Tire Capacity (lbs): 2335
• Spare Tire Capacity (lbs): 3042
• Revolutions/Mile @ 45 mph - Front: 706
• Revolutions/Mile @ 45 mph - Front: 678
• Revolutions/Mile @ 45 mph - Rear: 706
• Revolutions/Mile @ 45 mph - Rear: 678
• Revolutions/Mile @ 45 mph - Spare: 706
• Revolutions/Mile @ 45 mph - Spare: 678
• Wheels
• Front Wheel Size (in): 16 x 6.0
• Front Wheel Size (in): 16 x 6.5
• Rear Wheel Size (in): 16 x 6.0
• Rear Wheel Size (in): 16 x 6.5
• Spare Wheel Size (in): 16 x 6.0
• Spare Wheel Size (in): 16 x 6.5
• Front Wheel Material: Steel
• Rear Wheel Material: Steel
• Spare Wheel Material: Steel
• Steering
• Steering Type: Power
• Steering Ratio (:1), On Center: 16.4
• Steering Ratio (:1), At Lock: 16.3
• Turning Diameter - Curb to Curb (ft): - TBD -
• Turning Diameter - Curb to Curb (ft): 55.7
• Turning Diameter - Wall to Wall (ft): - TBD -
• Turning Diameter - Wall to Wall (ft): 59.5
• Frame
• Frame Type: Ladder
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 34
• Fuel Tank Location: Inboard LH Frame
• Exterior Dimensions
• Wheelbase (in): 168.5
• Length, Overall w/o rear bumper (in): 250.9
• Width, Max w/o mirrors (in): 94.3
• Width, Max w/o mirrors (in): 76.8
• Height, Overall (in): 74.5
• Overhang, Front (in): 35.4
• Overhang, Rear w/o bumper (in): 46.5
• Front Bumper to Back of Cab (in): 148.5
• Cab to Axle (in): 55.9
• Ground to Top of Load Floor (in): 34.7
• Ground to Top of Load Floor (in): 34.2
• Frame Width, Rear (in): 36.7
• Ground Clearance, Front (in): 7.3
• Ground Clearance, Rear (in): 6.4
• Cargo Area Dimensions
• Cargo Box Length @ Floor (in): 97.6
• Cargo Box Width @ Top, Rear (in): 60.2
• Cargo Box Width @ Floor (in): 64.4
• Cargo Box Width @ Wheelhousings (in): 49.1
• Cargo Box (Area) Height (in): 19.2
• Tailgate Width (in): 62.0
• Cargo Volume (ft³): 69.1
• Interior Dimensions
• Passenger Capacity: 5
• Passenger Capacity: 6
• Front Head Room (in): 40.0
• Front Leg Room (in): 41.5
• Front Shoulder Room (in): 65.0
• Front Hip Room (in): 60.1
• Second Head Room (in): 40.8
• Second Leg Room (in): 37.9
• Second Shoulder Room (in): 64.9
• Second Hip Room (in): 59.3
• Summary
• Vehicle Name: GMC Sierra 3500 Crew Cab
• Body Style: 4 Door 8' Wideside
• Body Code: E63
